BW series L-shape postitoner welding workstation
Type
Single machine series
The dual-axis L-type positioner, also known as the L-type positioner welding workstation, falls under the category of welding robot workstations. The entire system adopts a collaborative operation configuration integrating robots, complete laser welding units and positioners.
BW series L-shape postitonerwelding workstation
| Customization： | Available |
| Welding method： | Arc Welding Robot |
| Accuracy： | 0.5mm |
| Application： | Aerospace Industry, Automotive Industry, Construction Industry, Metal Fabrication Industry, Shipbuilding Industry |
| Welding Speed： | 0.5 m/min |
| Model NO： | KSBW0211 |
| Advantage： | No Teaching and Programming |
The world’s first teach-free and programming-free welding system, led by Connect Robotics, can reverse-engineer workpiece models through large-area line scanning, eliminating the need for drawings. With this system, a single operator can run 3 to 4 of our machines simultaneously.
Simply place the workpiece within the scannable range, and our robot will automatically scan, plan the path, and perform the welding.
Say goodbye to the hassles of teaching and programming.
Factory Planning
We offer customized factory layout designs to optimize workflow, space utilization, and productivity for your H-beam fabrication facility.
Installation&Commissioning
Our experienced team handles the entire installation process, ensuring your equipment is fully operational and fine-tuned for peak performance.
Onsite Training
We provide thorough training programs to equip your staff with the skills needed to operate and maintain our equipment effectively.
Consumables Supply
We supply high-quality consumables to ensure uninterrupted production and maintain the longevity of your equipment.
Product Details
| CONTENT | PARAMETER RANGE | UNIT | NOTES |
|---|---|---|---|
| series | Single machine series | / | Can be equipped with 2 dual axis positioners |
| Model Number | KSBW0212 | / | / |
| Degrees of Freedom | 6+2+2 | / | / |
| Required Ambient Temperature | -10~45 | ℃ | / |
| Maximum End Load | 6 | Kg | / |
| Working Range | W1800*L3000*H600 | mm | / |
| Peak Total Power | 45 | Kg | / |
| Rated Input Voltage | 380+/-10% | V | three-phase electricity |
| Rated Input Frequency | 50 | Hz | / |
| Footprint | 2400*2400 | mm | / |
| Color Customization | specified location | set | / |
| Customized labeling | specified location | set | / |
The Dual-Axis L-Type Positioner, also referred to as an L-type positioner welding workstation, is a type of welding robot workstation. The system adopts a collaborative operation mode of “robot + laser welding kit + positioner,” where the L-type positioner works in tandem with the welding robot to perform flipping and rotating welding tasks. It supports the combination of manual pre-tack welding and fully automated long-seam welding by the robot, making it suitable for manufacturing products that require high precision, sealing performance, and appearance quality in welds.
Applications of the Dual-Axis L-Type Positioner
A positioner is a practical auxiliary positioning device suitable for the automated welding of small, medium, and large workpieces that need to be flipped on multiple sides before all welds are completed.
Advantages of the Dual-Axis L-Type Positioner
The system can be paired with a laser tracking system to compensate for workpiece assembly deviations. It is equipped with a 2kW laser generator and an adjustable spot welding head, supporting real-time adjustment of various spot profiles and parameters to meet different welding requirements.
The maximum weldable workpiece size reaches 1000mm × 1500mm × 1000mm (length × width × height). The positioner has a load capacity of 500kg and a tooling disk diameter of 1600mm, making it suitable for medium to large workpieces.
The equipment is easy to operate. After short-term training to learn basic process programming, operators can independently run the device. Once the workpiece is loaded, the entire process requires no manual intervention, significantly reducing the skill requirements for operators.
Product Gallery
Subsequent changes to these parameters will not be notified separately. For inquiries and quotations, please call or contact our customer service specialists.
